Apply to all kinds of wooden doors and metal doors.
Tubular type.
Distinguished entrance trim designs with rich styles, finish selections and levers of
configurability.
Heavy-duty,10 years mechanical warranty under correct installation and normal usage.
The 3 generation tubular mechanism with anti-saw function.
The 3 generation high-tech cylinder with secure keyway and construction key function.
Easily reversible for left and right opening doors.
Easy installation, instruction manual included.
THE 3rd GENERATION HIGH-TECH CYLINDER
High-tech solid brass cylinder(Brass for housing, core/plug, pins and nut).
Machined by precise CNC(Computer Numeric Control) equipments according to the most strict QA standard.
Keyway: Double-Row-Pin technology, 10 pins, pin-combinations are much more than international standard, extremely security.
Construction key function available: Each cylinder with 5 pcs OWNER keys +1 pc CONSTRUCTION key, all keys are made by solid brass, thickness 2.5mm.
Hardened process for tail-piece, stronger and more durable.
Key Features:
1. H.264, Megapixel. Hi 3518E. CMOS, DC 5V2A.
2. 11 LED, IR distance 10M. Lens 3.6 mm
3. Two-way audio, Indoor
4. Wi-Fi/802.11/b/g/n ,PC CMS to control multi-cameras. AP Function( easy to connect wifi).
5. Motion detection, email alert, FTP upload
6.Support Video Mask and Special Area Detection
7.15 languages APP & WEB UI, Firefox, Safari, Google browser
8. Color: White
9.P2P, PNP: Plug&play, Support QR code scanning to view on Iphone and android Mobile
10.Support Max 128 G TF Card.
11.Support standard onvif protocol
Specifications:
| Model No: HW0041 | ||
| Ssystem | System Security | Supports there-level account, password, user authority management. |
| OS | Embedded Linux OS | |
| Processor | Hi3518E | |
| P2P (Free) | No need to preset camera, Offer free P2P(HWAA-000xxx-xxxxx), Plug&play, Support QR code scanning to view | |
| Onvif Protocol | Support ONVIF Protocol | |
| Multi-device function | Support 12 language remote surveillance, record, alarm, wifi setting etc. | |
| PC client | Support remote multi-devices monitor, record, alarm etc. | |
| Cell Phone View | Self R&D APP, Support Iphone,Android smart Phone | |
| TF Card Record | Support Max 128G TF card .Support the scheduled record,scheduled snapshot,Support Intelligent record playback via browser | |
| Lens | Lens Type | Lens Standard : 3.6 mm |
| IR-CUT | Build-in IR CUT, no color cast,auto switch when IR on | |
| Video | Image Compression | H.264/MJPEG |
| Sensor | 1/4 Cmos 1MP | |
| Video Parameters | Brightness, Contrast,Saturation,Exposure,sharpness,VerticalAnd Horizontal can be adjusted | |
| Image Frame Rate | 50Hz:25fps/60HZ:30fps (1280×720) | |
| First Stream | 720P-(1280x720),(640x352) | |
| Second Stream | VGA-(640x352),(320x176) | |
| Audio | Compression format | G.726/G.711(G.711 Default) |
| Audio In | Built in Mic,also external supported | |
| Audio Out | Built in Speaker,also external supported | |
| Night Vision | Lux | 0 LUX |
| Night Visibility | 11 Φ5 IR LEDs, Night visibility up to 10 meters | |
| Pan/Tilt | Preset | Support 8 Preset Positions |
| Rotation Angle | Pan:355°, Tilt: 90° | |
| Rotation Speed | Pan: Speed Range 5-30°/ S; Tilt: Speed Range 5-50°/ S; | |
| Alarm | Motion Detect | Support 4 Independent detection areas(Sensitivity can be adjustd 1-100) |
| Alarm Action | Support Email Photo Alert,Snapshot and Record uploaded to FTP or TF Card | |
| Network | Ethernet Interface | One 10/100Mbps RJ-45 |
| Supported Protocol | TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP etc. | |
| Access Protocol | Onvif protocol | |
| IP Mode | Dynamic IP address, static IP address, PPPOE | |
| Online Visitor | Support Max 6 visitors at the same time (First Stream:3 visitors;Second Stream:3 visitors) | |
| Supported OS | Support Microsoft Win XP/Win7/Win8/ Mac OS. | |
| Browser | Support Internet Explorer ,FireFox,Google Browser, etc | |
| AP Function | Support AP connect WIFI | |
| Wireless Standard | WIFI, 802.11b/g/n | |
| Others | OSD | Support the OSD name, date and time info superposition(Open/Off) |
| Product Type | Cartoon Robot/ Indoor use | |
| Color | White | |
| Power | DC5V 2A | |
| Working Temperature | –10~50℃ | |
| Working Humidity | 95% RH | |
| Size | Item:(125mmx120mm) (HxW); Packaging:182mmx118mmx149mm (LxWxH) | |
| Weight | N.W.: 310g G.W.: 600g(Note:Actual Weight Final) | |
| Accessories | Adaptor, User manual,Bracket,Screws | |
| Certification | CE,FCC,RoHS | |
| Warranty | Limited 2-Year Warranty | |
Pictures:
Before sales service:
1, We provide Sample demo online view.
2, We provide OEM service and ODM service.
After sales service
1, All our ip camera have 2 year warranty.
2, We provide professional support to answer your quetions and solve your problems.
In future, we will always try our best to make high quality, popular and reliable chinese door lock products for our customers.
