Supplying size for the lock case
Standard: 45*85mm, 60*85mm
Customized: 50*85mm, 70*85mm, 45*72mm, 55*72mm, 60*72mm
Color box packing
12 pcs/ctn
32kg/ctn
Carton size: 70*36*33cm
62 FIVE IN ONE LAND SURVEYING COMPASS
62 Type five-use military compass
The main function of five-use compass is:
Determining direction, estimating distance, measuring angle of pitching and calibrating level. Also it can measure the mileage between teo arbitary points in map and the coordinate of one point. It also can be usded to the night operation.
AZIMUTH MEASURING MECHANISM
It consists of magnetic needle system, azimuth dial, counter-clockwise digital azimuth dial (which would be clockwise as viewed from reflective mirror), sight port and head, etc. Full graduation of azimuth is 360° for outer circle and 6000 mil for inner circle.
Procedures to measure azimuth angles in the open is as following: first open the compass, lay the counter-clockwise digital azimuth dial flat; then turn the reflective mirror to 45°, and obeserve the azimuth angle from the mirror. The graduation pointed by the magnetic needle “N”(north) pole is read as azimuth angle.
62 Type five-uses military compass
Function | range | graduation | precision |
Position Measure | 6000 mil | 20mil | 20mil |
360° | 2° | 1° | |
Angle of Depression and Elevation | 60° | 5° | 2.5° |
Distance Eatimation | Proportion 10:1, 20:1 | 5% | |
Mileage measure | Proportion(km) 1:100000, 1:50000, 1:25000 | 2% | |
Survey ruler | 100mm | 1mm | Total length 0.5mm |
In future, we will always try our best to make high quality, popular and reliable chinese door lock products for our customers.
