FUYU internal door locks manufacturer for wooden door2
-
v s
1. The principal part of internal door locks is made by advanced residential doors.
2. It satisfies all of the International quality standards, which are very strict.
3. Long operation life absolutely manifests its superior performance.
4. Zhongshan Fuyu Hardware Products Co., Ltd. makes efforts to set an example as a reliable enterprise.
MAIN SPECIFICATIONS
Apply to all kinds of wooden doors and metal doors.
Global first-creative revolutionary design for lock case.
Mortise type.
ANSI/BHMA Grade 2 A156.13 standard.
800,000 cycles.
Patented products.
Fire-proof mechanism.
Anti-drill cylinder.
Construction key function.
Anti-insert and silent-closed three-piece latch.
Anti-cut bolt.
Anti-panic.
Auto-locking.
Easily reversible for left and right handing.
PATENT CERTIFICATE
ANSI/BHMA GRADE 2 CERTIFICATE BY INTERTEK
ASSEMBLY ILLUSTRATION
SUPPLYING FUNCTION FOR RESIDENTIAL
Entrance
Dummy
Two-open Door
BOX DESIGN
SUPPLYING FUNCTION FOR ANSI/BHMA STANDARD
| FUYU CODE | DESCRIPTION | FUNCTION | ANSI ANSI NO. |
82F01 | Passage Latch | Latchbolt retracted by knob/lever from either side at all times. |
F01 |
82F02 |
Privacy/Bathroom Lock | Latchbolt retracted by knob/lever from either side. Deadbolt thrown or retracted by emergency turn outside or thumbturn inside. | F02 |
82F14 |
Store/Utility Room Lock | Latchbolt retracted by knob/lever from either side. Deadbolt thrown or retracted by key from either side. |
F14 |
82F16 | Double Cylinder Lock | Deadbolt operated by key from either side. | F16 |
82F17 | Cylinder x Thumbturn Lock | Deadbolt thrown or retracted by key outside or thumbturn inside. | F17 |
82F18 |
Cylinder w/o turn Lock | Deadbolt thrown or retracted by key from one side.No trim on opposite side. | F18 |
82F21 |
Dormitory/Bedroom Lock | Latchbolt retracted by knob/lever from either side. Deadbolt thrown or retracted by key outside or thumbturn inside. | F21 |
82F25 | Storeroom with grip handle Lock | Latchbolt retracted by thumb button from either side.Deadbolt operated by key from either side. | F25 |
DETAILS DESCRIPTION FOR CYLINDER
Anti-drill American sytle cylinder.
With construction key function.
Solid brass cylinder(Brass housing, plugs and pins).
With American angle-cut-pin technology, each pin is
different from both angle and length, ensure top
security performance.
Processed with CNC (Computer Numeric Control)
machines, key-combination is over international
standard.
Each cylinder with 5 pcs cupronickel
owner keys, 1 pc brass construction and
1pc installation key. Angle-cut-pin
keyway, each set of keys with a solo
keyway code tag, make your keys not to
be duplicated by others.
Thickness of Key is 3.0mm.
THE STRUCTURE OF CYLINDER WITH ANGLE-CUT-PIN A B KEYS
Company Features
1. Zhongshan Fuyu Hardware Products Co., Ltd. is an advanced enterprise in internal door locks industry with top-class technology, talents, and brands.
2. FUYU establishes competent labs to manufacture handle door lock .
3. Fuyu Door Lock Manufacturers provides ONE-STOP PURCHASE to create great convenience for you. Get an offer! The excellence in quality of entry door locks is our promise. Get an offer! Under the guidance of spirit of enterprise, FUYU has been adhering to pursuing the better quality of grip handle door lock . Get an offer!
In future, we will always try our best to make high quality, popular and reliable chinese door lock products for our customers.
