FUYU removing file cabinet lock in china for residential
MAIN SPECIFICATIONS
Apply to all kinds of wooden doors and metal doors.
Global first-creative revolutionary design for lock case.
Mortise type.
ANSI/BHMA Grade 2 A156.13 standard.
800,000 cycles.
Patented products.
Fire-proof mechanism.
Anti-drill cylinder.
Construction key function.
Anti-insert and silent-closed three-piece latch.
Anti-cut bolt.
Anti-panic.
Auto-locking.
Easily reversible for left and right handing.
PATENT CERTIFICATE
ANSI/BHMA GRADE 2 CERTIFICATE BY INTERTEK
ASSEMBLY ILLUSTRATION
SUPPLYING FUNCTION FOR RESIDENTIAL
Entrance
Dummy
Two-open Door
BOX DESIGN
SUPPLYING FUNCTION FOR ANSI/BHMA STANDARD
| FUYU CODE | DESCRIPTION | FUNCTION | ANSI ANSI NO. |
82F01 | Passage Latch | Latchbolt retracted by knob/lever from either side at all times. |
F01 |
82F02 |
Privacy/Bathroom Lock | Latchbolt retracted by knob/lever from either side. Deadbolt thrown or retracted by emergency turn outside or thumbturn inside. | F02 |
82F14 |
Store/Utility Room Lock | Latchbolt retracted by knob/lever from either side. Deadbolt thrown or retracted by key from either side. |
F14 |
82F16 | Double Cylinder Lock | Deadbolt operated by key from either side. | F16 |
82F17 | Cylinder x Thumbturn Lock | Deadbolt thrown or retracted by key outside or thumbturn inside. | F17 |
82F18 |
Cylinder w/o turn Lock | Deadbolt thrown or retracted by key from one side.No trim on opposite side. | F18 |
82F21 |
Dormitory/Bedroom Lock | Latchbolt retracted by knob/lever from either side. Deadbolt thrown or retracted by key outside or thumbturn inside. | F21 |
82F25 | Storeroom with grip handle Lock | Latchbolt retracted by thumb button from either side.Deadbolt operated by key from either side. | F25 |
DETAILS DESCRIPTION FOR CYLINDER
Anti-drill American sytle cylinder.
With construction key function.
Solid brass cylinder(Brass housing, plugs and pins).
With American angle-cut-pin technology, each pin is
different from both angle and length, ensure top
security performance.
Processed with CNC (Computer Numeric Control)
machines, key-combination is over international
standard.
Each cylinder with 5 pcs cupronickel
owner keys, 1 pc brass construction and
1pc installation key. Angle-cut-pin
keyway, each set of keys with a solo
keyway code tag, make your keys not to
be duplicated by others.
Thickness of Key is 3.0mm.
THE STRUCTURE OF CYLINDER WITH ANGLE-CUT-PIN A B KEYS
